APEXX Front Forward Control Arms Can-Am Outlander/Renegade

This item qualifies for Free Shipping
  • HDFFA-C1OL-*
  • Category: APEXX Control Arms
  • Brand: High Lifter
  • Summary: All new High Lifter APEXX Control Arms are stronger, adjustable and engineered for the most punishing terrain with 1.75” of additional ground clearance and raked forward 2”. Push your machine to the limits and tackle obstacles you couldn't before!
  • Weight: 0.000000
  • Length: 0.000000
  • Width: 0.000000
  • Height: 0.000000

Features

  • Adjustable heat-treated collars for camber adjustability with a 1” thread
  • Raked forward 1.5"
  • Over 3 degrees of camber adjustment in each direction
  • Heavy duty ball joint brackets to eliminate deformation issues, Keller ball joint compatible
  • Control Arm Link Bars compatible with the 1.5” ID clamps
  • Extreme duty 1.5” x .120” DOM steel construction
  • Up to 2” of added ground clearance compared to OEM lower arm
  • Mounting accommodations for OEM brake lines using OEM tabs instead of P-clamps
  • Optimized sway bar linkage angles
  • Limited Lifetime Warranty (Excludes wearable items like bushings, bearings, cones, and heim joints)
  • Powder Coated

Heavy Duty Strength
High Lifter’s new heavy duty control arms add more support than factory. Our upper and lower arms are made with the same material for added strength, so they can withstand the abuse applied during a typical ride. High Lifter arms are constructed out of 1.5” DOM with .120” wall tubing. This is a 50% increase in size and a 70% increase in steel thickness for added durability and strength.

Built in Adjustability
The lower arms also feature an adjustability component in the bushing collars to make installation easier and faster. When the kit is set to the factory position, you have 3/8” of adjustability camber in and out. Heat treated and plated adjustable bushing collars allow you to be confident in the strength you’re adding to your ride. This kit comes packaged and preadjusted to the factory position, and factory bushings and caps should be used for installation.

Increased Ground Clearance
We maximized ground clearance by strategically arching the lower control arm with double and TRIPLE bends. This unique design allowed us to get an additional 1.75” of ground clearance to avoid impacting those nasty trail obstacles. These bends maintain the factory geometry, which helps reduce wear on components like axles and tie rods. Our forward arms allow you to run larger tires without a suspension lift. We’ve improved the upper control arm by repositioning the sway bar tab. This will reduce the extreme angles places on the sway bar links and reduce wear.

Reinforced Ball Joints Brackets
Portals and large tires apply torque that can distort the ball joint bracket, leading to failure of the arms. With over 130% increase in the ball joint mounting area, we are helping to prevent breakdown or “egging” of the mounting bracket.

Tire Fitment: Up to 31" without lift kit and up to 33" with lift kit.
Our tire fitment guide is a general fitment and is in no way guaranteed. Tires and lifts vary by manufacture and tire fitment can be affected by other modifications such as, but not limited to, wheel offset, actual tire diameter and actual tire width. Always verify your brand of tires, lift, and other modifications prior to making a buying decision.

Optional Preinstalled Ball Joints
High Lifter’s service team uses a hydraulic press to install the ball joint with the correct pressure and alignment, also making sure the clip is fully seated and secured. Purchasing control arms with the ball joints already installed adds to easy installation and prevents damage due to improper installation, which is not covered by High Lifter’s Lifetime Warranty.

2022 Can-Am Outlander 650
2022 Can-Am Outlander 650 DPS
2022 Can-Am Outlander 650 XT
2022 Can-Am Outlander 650 Mossy Oak
2022 Can-Am Outlander 650 XMR
2022 Can-Am Outlander 650 MAX XT
2022 Can-Am Outlander 650 MAX 6x6 DPS
2022 Can-Am Renegade 650 XMR
2022 Can-Am Renegade 570
2022 Can-Am Outlander 850
2022 Can-Am Outlander 850 DPS
2022 Can-Am Outlander 850 XT
2022 Can-Am Outlander 850 XT-P
2022 Can-Am Outlander 850 XMR
2022 Can-Am Outlander 850 MAX XT
2022 Can-Am Renegade 850
2022 Can-Am Outlander 850 MAX XT-P
2022 Can-Am Renegade 850 XXC
2022 Can-Am Outlander 1000R XT
2022 Can-Am Outlander 1000R XTP
2022 Can-Am Outlander 1000R XXC
2022 Can-Am Outlander 1000R XMR
2022 Can-Am Outlander 1000R MAX XT
2022 Can-Am Outlander 1000R MAX XTP
2022 Can-Am Outlander 1000R MAX LTD
2022 Can-Am Outlander 6x6 1000 XT
2022 Can-Am Renegade 1000R XXC
2022 Can-Am Renegade 1000R XMR
2019 Can-Am Outlander 1000 Mossy Oak Hunting
2019 Can-Am Outlander 650 MAX North Edition
2019 Can-Am Outlander 650 North Edition
2019 Can-Am Outlander 850 MAX North Edition
2019 Can-Am Outlander 850 North Edition
2020 Can-Am Outlander 1000 DPS
2020 Can-Am Outlander 850 MAX North Edition
2020 Can-Am Outlander 850 North Edition
2021 Can-Am Outlander 1000 DPS
2021 Can-Am Outlander 650 XMR
2022 Can-Am Outlander 650 MAX DPS
2020 Can-Am Outlander 650 Mossy Oak Hunting
2023 Can-Am Outlander 1000 MAX XT 6x6
2023 Can-Am Outlander 1000R MAX LTD
2023 Can-Am Outlander 1000R XMR
2023 Can-Am Outlander 1000R XXC
2023 Can-Am Outlander 650 MAX 6x6 DPS
2023 Can-Am Outlander 850
2023 Can-Am Outlander 850 DPS
2023 Can-Am Outlander 850 Hunting
2023 Can-Am Outlander 850 MAX DPS
2023 Can-Am Outlander 850 MAX XT
2023 Can-Am Outlander 850 MAX XT-P
2023 Can-Am Outlander 850 XMR
2023 Can-Am Outlander 850 XT
2023 Can-Am Outlander 850 XT-P
2023 Can-Am Renegade 1000R XMR
2023 Can-Am Renegade 1000R XXC
2023 Can-Am Renegade 650
2023 Can-Am Renegade 650 XMR
2019 Can-Am Outlander 1000 DPS
2019 Can-Am Outlander 1000 XMR
2019 Can-Am Outlander 1000 XT
2019 Can-Am Outlander 1000 XT-P
2019 Can-Am Outlander 1000 XXC
2019 Can-Am Outlander 1000 MAX LTD
2019 Can-Am Outlander 1000 MAX XT
2019 Can-Am Outlander 1000 MAX XT-P
2019 Can-Am Outlander 650
2019 Can-Am Outlander 650 DPS
2019 Can-Am Outlander 650 XT
2019 Can-Am Outlander 650 XMR
2019 Can-Am Outlander 650 MAX
2019 Can-Am Outlander 650 MAX DPS
2019 Can-Am Outlander 650 MAX XT
2019 Can-Am Outlander 850 MAX
2019 Can-Am Outlander 850 MAX XT-P
2019 Can-Am Outlander 850 MAX XT
2019 Can-Am Outlander 850
2019 Can-Am Outlander 850 DPS
2019 Can-Am Outlander 850 XMR
2019 Can-Am Outlander 850 XT
2019 Can-Am Outlander 850 XT-P
2019 Can-Am Outlander 6x6 1000 XT
2019 Can-Am Outlander 6x6 650 DPS
2019 Can-Am Renegade 1000
2019 Can-Am Renegade 1000 XMR
2019 Can-Am Renegade 1000 XXC
2019 Can-Am Renegade 570
2019 Can-Am Renegade 570 XMR
2019 Can-Am Renegade 850
2019 Can-Am Renegade 850 XXC
2019 Can-Am Outlander 6x6 450 MAX DPS
2020 Can-Am Outlander 1000 XMR
2020 Can-Am Outlander 1000 XT
2020 Can-Am Outlander 1000 XT-P
2020 Can-Am Outlander 1000 XXC
2020 Can-Am Outlander 1000 MAX LTD
2020 Can-Am Outlander 1000 MAX XT
2020 Can-Am Outlander 1000 MAX XT-P
2020 Can-Am Outlander 650
2020 Can-Am Outlander 650 DPS
2020 Can-Am Outlander 650 XT
2020 Can-Am Outlander 650 XMR
2020 Can-Am Outlander 650 MAX DPS
2020 Can-Am Outlander 650 MAX XT
2020 Can-Am Outlander 850 MAX XT-P
2020 Can-Am Outlander 850 MAX XT
2020 Can-Am Outlander 850
2020 Can-Am Outlander 850 DPS
2020 Can-Am Outlander 850 XT
2020 Can-Am Outlander 850 XMR
2020 Can-Am Outlander 850 XT-P
2020 Can-Am Outlander 6x6 1000 XT
2020 Can-Am Outlander 6x6 650 DPS
2020 Can-Am Renegade 1000 XMR
2020 Can-Am Renegade 1000 XXC
2020 Can-Am Renegade 570
2020 Can-Am Renegade 570 XMR
2020 Can-Am Renegade 850
2020 Can-Am Renegade 850 XXC
2021 Can-Am Renegade 1000R XMR
2021 Can-Am Renegade 1000R XXC
2021 Can-Am Renegade 850
2021 Can-Am Renegade 850 XXC
2021 Can-Am Renegade 570
2021 Can-Am Renegade 570 XMR
2021 Can-Am Outlander 1000R XT
2021 Can-Am Outlander 1000R XTP
2021 Can-Am Outlander 1000R XXC
2021 Can-Am Outlander 1000R XMR
2021 Can-Am Outlander 1000R MAX XT
2021 Can-Am Outlander 1000R MAX XTP
2021 Can-Am Outlander 1000R MAX LTD
2021 Can-Am Outlander 850
2021 Can-Am Outlander 850 DPS
2021 Can-Am Outlander 850 XT
2021 Can-Am Outlander 850 XTP
2021 Can-Am Outlander 850 North Edition
2021 Can-Am Outlander 850 XMR
2021 Can-Am Outlander 850 MAX XT
2021 Can-Am Outlander 850 MAX XTP
2021 Can-Am Outlander 850 MAX North Edition
2021 Can-Am Outlander 650
2021 Can-Am Outlander 650 DPS
2021 Can-Am Outlander 650 XT
2021 Can-Am Outlander 650 Mossy Oak
2021 Can-Am Outlander 650 MAX DPS
2021 Can-Am Outlander 650 MAX XT
2021 Can-Am Outlander 1000 MAX 6x6 XT
2021 Can-Am Outlander 650 MAX 6x6 DPS
