APEXX Front Forward Control Arms Can-Am Defender XMR

This item qualifies for Free Shipping
  • HDFFA-C1DXMR-*
  • Category: APEXX Control Arms
  • Brand: High Lifter
  • Summary: All new High Lifter APEXX Control Arms are stronger, adjustable and engineered for the most punishing terrain with 1.75" of additional ground clearance and raked forward 2". Push your machine to the limits and tackle obstacles you couldn't before!
  • Weight: 71.13

Features

  • Adjustable heat-treated collars for camber adjustability with a 1" thread
  • Raked forward 2"
  • Over 3 degrees of camber adjustment in each direction
  • Heavy duty ball joint brackets to eliminate deformation issues, Keller ball joint compatible
  • Ladder bar compatible with the 1.5" ID clamps
  • Extreme duty 1.5" x .120" DOM steel construction
  • Up to 2" of added ground clearance compared to OEM lower arm
  • Mounting accommodations for OEM brake lines using OEM tabs instead of P-clamps
  • Optimized sway bar linkage angles
  • Limited Lifetime Warranty (Excludes wearable items like bushings, bearings, cones, and heim joints)
  • Powder Coated

Heavy Duty Strength
High Lifter's new heavy duty control arms add more support than factory. Our upper and lower arms are made with the same material for added strength, so they can withstand the abuse applied during a typical ride. High Lifter arms are constructed out of 1.5" DOM with .120 wall tubing. This is a 50% increase in size and a 70% increase in steel thickness for added durability and strength.

Built in Adjustability
The lower arms also feature an adjustability component in the bushing collars to eliminate premature wearing that can come from the addition of lift kits, portals, or larger tires. When the kit is set to the factory position, you have 3/8" of adjustability camber in and out. Heat treated and plated adjustable bushing collars allow you to be confident in the strength you're adding to your ride. This kit comes packaged and preadjusted to the factory position, and factory bushings and caps should be used for installation.

Increased Ground Clearance
We maximized ground clearance by strategically arching the lower control arm with double bends. This unique design allowed us to get an additional 1.75" of ground clearance to avoid impacting those nasty trail obstacles. These bends maintain the factory geometry, which helps reduce wear on components like axles and tie rods. Our forward arms allow you to run larger tires without a suspension lift. We've improved the upper control arm by repositioning the sway bar tab. This will reduce the extreme angles places on the sway bar links and reduce wear.

Reinforced Ball Joints Brackets
Portals and large tires apply torque that can distort the ball joint bracket, leading to failure of the arms. With over 130% increase in the ball joint mounting area, we are helping to prevent breakdown or "egging" of the mounting bracket.

Tire Fitment: Up to 34.5"
Our tire fitment guide is a general fitment and is in no way guaranteed. Tires and lifts vary by manufacture and tire fitment can be affected by other modifications such as, but not limited to, wheel offset, actual tire diameter and actual tire width. Always verify your brand of tires, lift, and other modifications prior to making a buying decision.

Optional Preinstalled Ball Joints
High Lifter's service team uses a hydraulic press to install the ball joint with the correct pressure and alignment, also making sure the clip is fully seated and secured. Purchasing control arms with the ball joints already installed adds to easy installation and prevents damage due to improper installation, which is not covered by High Lifter's Lifetime Warranty.

2022 Can-Am Defender HD10 Limited
2022 Can-Am Defender HD10 X mr
2022 Can-Am Defender MAX HD10 Lone Star
2022 Can-Am Defender MAX HD10 Limited
2022 Can-Am Defender Max HD10 X MR
2022 Can-Am Defender HD10 PRO Lone Star
2022 Can-Am Defender HD10 PRO Limited
2020 Can-Am Defender HD10 Limited
2023 Can-Am Defender HD10 CAB DPS Limited
2023 Can-Am Defender HD10 CAB XT Limited 6x6
2023 Can-Am Defender HD10 X mr
2023 Can-Am Defender HD10 X MR with Half Doors
2023 Can-Am Defender MAX HD10 CAB XT Limited
2023 Can-Am Defender MAX HD10 Lone Star
2023 Can-Am Defender MAX HD10 Lone Star CAB
2023 Can-Am Defender Max HD10 X MR
2023 Can-Am Defender Max HD10 X MR with Half Doors
2023 Can-Am Defender HD10 PRO Limited
2023 Can-Am Defender HD10 Limited
2021 Can-Am Defender HD10 Limited
2021 Can-Am Defender MAX HD10 Limited
2024 Can-Am Defender HD10 Limited
2024 Can-Am Defender HD9 DPS Cab
2024 Can-Am Defender HD10 PRO Limited
2020 Can-Am Defender HD10 X mr
2020 Can-Am Defender HD10 XT Cab
2020 Can-Am Defender HD8 XT Cab
2020 Can-Am Defender Max HD10 XT Cab
2020 Can-Am Defender MAX HD10 Lone Star
2020 Can-Am Defender Max HD10 X MR
2021 Can-Am Defender HD10 X mr
2021 Can-Am Defender HD8 CAB DPS
2021 Can-Am Defender MAX HD10 Lone Star
2021 Can-Am Defender Max HD10 X MR

Product Ratings and Reviews

Add a Review

4.0 out of 5 stars
  • Saturday, April 27, 2024
  • Dave
The a arms are very beefy and stout. NOTE!!! they do not come bushings. They did give the camber adjustment I needed. I have them on a Can am defender 6x6 limited. My turning radius is now just over 40 cares with them on. They are what I needed.

Click here for High Lifter's Outlaw DHT XL Big Lift Axle Warranty Program.
