Rear Lower Control Arms Honda Pioneer 1000

This item qualifies for Free Shipping
  • MCRLA-H1P-*
  • Category: Control Arms
  • Brand: High Lifter
  • Summary: Whether you ride in deep mud or over rocky trails, the need for stronger control arms with added ground clearance is extremely important. Most stock arms are too weak to withstand what you put your bike through and lack the added ground clearance needed for challenging trails. High Lifter has solved your problem by designing tough control arms, twice as strong as your stock arms, with the added ground clearance you need for all terrains and bigger tires.
  • Weight: 29.69
  • Length: 26
  • Width: 15
  • Height: 7

Our arms maximize ground clearance by strategically arching the lower control arms while following the angle of the axle for maximum clearance, axle protection, and visual appeal. Don't be fooled with too much arch that puts your axles into greater risk of damage. Our precision manufacturing process ensures each control arm installs exactly like the factory arm. Depending on the model, most kits will have the High Lifter logo precision cut into the bracing.

Installation is made easy with our step by step and multi-image instructions. During installation, you can use stock bushings and ball joints for easy installation. Even better, High Lifter will install your ball joints before shipping. (See our control arms with preinstalled ball joints.)

Always check for bearings, bushings, ball joints, and brake wear before installation and replace if needed. We always recommend checking these parts before you start your installation to save time and get back on the trail sooner. See the Replacement Parts Tab to purchase replacement parts as needed.

Features:

  • 25% larger than average stock arms - Crafted from 1 1/4" DOM steel
  • Up to 2.5x the wall thickness of an average stock arms - .188" wall thickness
  • Grease fittings included for most models
  • Added ground clearance featuring bends that maximize clearance and axle protection
  • Most stock powder coat colors available in stock
  • Easy to install and maintain with camber adjustment
  • Limited Lifetime Warranty
Kit Includes: Bushings, Sleeves, Camber Adjustment Tab, and Grease Fittings.
2016 Honda Pioneer 1000-5
2016 Honda Pioneer 1000
2017 Honda Pioneer 1000
2017 Honda Pioneer 1000 EPS
2017 Honda Pioneer 1000 LE
2017 Honda Pioneer 1000-5
2017 Honda Pioneer 1000-5 Deluxe
2018 Honda Pioneer 1000
2018 Honda Pioneer 1000 EPS
2018 Honda Pioneer 1000 LE
2018 Honda Pioneer 1000-5
2018 Honda Pioneer 1000-5 Deluxe
2018 Honda Pioneer 1000-5 LE
2019 Honda Pioneer 1000
2019 Honda Pioneer 1000 EPS
2019 Honda Pioneer 1000 LE
2019 Honda Pioneer 1000-5
2019 Honda Pioneer 1000-5 Deluxe
2019 Honda Pioneer 1000-5 LE
2020 Honda Pioneer 1000
2020 Honda Pioneer 1000 Deluxe
2020 Honda Pioneer 1000-5
2020 Honda Pioneer 1000-5 Deluxe
2021 Honda Pioneer 1000
2021 Honda Pioneer 1000 Deluxe
2021 Honda Pioneer 1000 LE
2021 Honda Pioneer 1000-5
2021 Honda Pioneer 1000-5 Deluxe
2021 Honda Pioneer 1000-5 LE

Product Ratings and Reviews

Add a Review

5.0 out of 5 stars
  • Friday, April 29, 2022
  • Ben Wray
Great product , excellent customer service! Did just what I needed more ground clearance better stance while still being able to use stock axles, just wish they'd hurry up and make the uppers for the rear LOL
  • Monday, January 17, 2022
  • Tony Draper
These arms are GREAT... Gives me mucho more clearance than I had before. Very easy to install, and very heavy duty... Wish I'd bought these long ago. Thanks High Lifter !!!
  • Friday, January 14, 2022
  • Tony Draper
These are exactly what I was expecting them to do. Heavy duty, more clearance, no problems installing, and the look great. I've had side by sides for a few years, and High Lifter has been on all of them. Thanks High Lifter !
  • Wednesday, April 14, 2021
  • Drew Lawrence
Excellent customer service, excellent shipping time frame. Love my A Arms the extra addition was needing. Thanks
  • Friday, January 22, 2021
  • Ryan Williams
Great product!! Easy install. Only thing I would change is to make the chamber fully adjustable. Clearing my 30” tires no problem.
